Construction
Gears and transmission systems for construction equipment.
Carraro is a leading global Group in transmission systems for off-highway vehicles, both in construction & agricultural equipment.
More in detail, within construction equipment sector the Group develops gears and transmission systems for backhoe loaders, compact wheel loaders, telehandlers, wheeled excavators, aerial working platforms and soil compactors.
Each system involves a combination of axles and hydrostatic or hydrokinetic transmission with torque converter, with semi-automatic or fully automatic mode by means of an electronic control unit that manages the entire system. Every system component or module is designed to guarantee first-class vehicle efficiency and productivity.
Discover our range here below.
Telescopic Boom Handler
Axles
Key Features and Benefits
- The 46-Series Axles generation provides increased efficiency
- Tested for low power losses
- Designed and tested for use under any condition
- Improved serviceability reducing greasing points
Transmissions
Key Features and Benefits
- Power Shuttle and 4 or 6-speed Powershift
- Central and side drive configurations
- Full electronic or electro-hydraulic control
- Smooth, precise, and reliable response even under severe working conditions granted
Axles
Key Features and Benefits
- The 46-Series Axles generation provides increased efficiency
- Tested for low power losses
- Designed and tested for use under any condition
- Improved serviceability reducing greasing points
Transmissions
Key Features and Benefits
- Power Shuttle and 4 or 6-speed Powershift
- Central and side drive configurations
- Full electronic or electro-hydraulic control
- Smooth, precise, and reliable response even under severe working conditions granted
| Lift Capacity (Kg) | Front axle | Rear axle | Torque Converter Transmissions | ECU |
|---|---|---|---|---|
From 2750 / 6k to 4500 / 10k | 46.20M 46.24M 46.28M* 46.32M* | 46.20M 46.24M 46.28M* 46.32M* | TCH80 TCH90 PS Center Drive TCH90 PS Side Drive | Yes Yes |
From 4500 / 10k to 5500 / 12k | 46.37M 46.44M | 46.37M 46.44M | TCH80 TCH90 PS Center Drive TCH90 PS Center Drive | Yes Yes |
| * also available HY version | ||||
Telescopic Boom Handler
Axles
Key Features and Benefits
- The 46-Series Axles generation provides increased efficiency
- Tested for low power losses
- Designed and tested for use under any condition
- Improved serviceability reducing greasing points
Transmissions
Key Features and Benefits
- Complete range from compact dropbox to fully electronically controlled solutions
- Suitable for hydromotor up to 255cc/rev
- THE Solution. New range of interchangeable Transmissions for Hydrostatic & Electric applications
- THE Solution. Proprietary synchronized and Powershift architecture
Axles
Key Features and Benefits
- The 46-Series Axles generation provides increased efficiency
- Tested for low power losses
- Designed and tested for use under any condition
- Improved serviceability reducing greasing points
Transmissions
Key Features and Benefits
- Complete range from compact dropbox to fully electronically controlled solutions
- Suitable for hydromotor up to 255cc/rev
- THE Solution. New range of interchangeable Transmissions for Hydrostatic & Electric applications
- THE Solution. Proprietary synchronized and Powershift architecture
| Lift Capacity (Kg) | Front axle | Rear axle | Hydrostatic Transmissions | ECU |
|---|---|---|---|---|
Up to 2750 / 6k | 46.08M 46.12M 46.14M 46.16M 46.18M | 46.08M 46.12M 46.14M 46.16M 46.18M | TB135C TB172C TB172HVT TB172/2C Stop&Go | |
From 2750 / 6k to 4500 / 10k | 46.20M 46.24M 46.28M* 46.32M* | 46.20M 46.24M 46.28M* 46.32M* | TB172C TB172HVT TB172/2C Stop&Go TB172/2C Shift on Fly THE260/2 Synchro THE260/2 PS | Yes Yes Yes |
| From 4500 / 10k to 5500 / 12k | 46.37M 46.44M | 46.37M 46.44M | TB172HVT TB172/2C Stop&Go TB172/2C Shift on Fly THE260/2 Synchro THE260/2 PS | Yes Yes Yes |
| * also available HY version | ||||
Telescopic Boom Handler
Axles
Key Features and Benefits
- The 46-Series Axles generation provides increased efficiency
- E-Axles range with input flanged e-Motor suitable for compact Telehandlers
- P3 and P4 solutions for HEV and BEV vehicles
Transmissions
Key Features and Benefits
- Single speed and dual speed eGearboxes specifically designed for electric vehicles
- THE Solution. New range of interchangeable Transmissions for Hydrostatic & Electric applications
- THE Solution. Proprietary synchronized and Powershift architecture
- eMotors range suitable for low and high voltage
Axles
Key Features and Benefits
- The 46-Series Axles generation provides increased efficiency
- E-Axles range with input flanged e-Motor suitable for compact Telehandlers
- P3 and P4 solutions for HEV and BEV vehicles
Transmissions
Key Features and Benefits
- Single speed and dual speed eGearboxes specifically designed for electric vehicles
- THE Solution. New range of interchangeable Transmissions for Hydrostatic & Electric applications
- THE Solution. Proprietary synchronized and Powershift architecture
- eMotors range suitable for low and high voltage
| Lift Capacity (Kg) | Front axle | Rear axle | eGearbox | eMotor | ECU |
|---|---|---|---|---|---|
Up to 2750 / 6k | 46.08M 46.12M 46.14M 46.16M 46.18M | 46.08M 46.12M 46.14M 46.16M 46.18M | TB172C TB220 THE260/2 Synchro | 200 Series 200 Series 200 Series 200 Series | Yes Yes Yes Yes |
From 2750 / 6k to 4500 / 10k | 46.20M 46.24M 46.28M* 46.32M* | 46.20M 46.24M 46.28M* 46.32M* | TB220 THE260/2 Synchro THE260/2 PS | 200 Series 200 Series 200 Series | Yes Yes Yes |
| From 4500 / 10k to 5500 / 12k | 46.37M 46.44M | 46.37M 46.44M | THE260/2 Synchro THE260/2 PS | 270 Series 270 Series | Yes Yes |
| * also available HY version | |||||
Compact Wheel Loader
Axles
Key Features and Benefits
- The 46-Series Axles generation provides increased efficiency
- Tested for low power losses
- Improved serviceability reducing greasing points
- Modular and monolithic design for any need
Transmissions
Key Features and Benefits
- Complete range from compact dropbox to fully electronically controlled solutions
- Suitable for hydromotor up to 255cc/rev
- THE Solution. New range of interchangeable Transmissions for Hydrostatic & Electric applications
- THE Solution. Proprietary synchronized and Powershift architecture
Axles
Key Features and Benefits
- The 46-Series Axles generation provides increased efficiency
- Tested for low power losses
- Improved serviceability reducing greasing points
- Modular and monolithic design for any need
Transmissions
Key Features and Benefits
- Complete range from compact dropbox to fully electronically controlled solutions
- Suitable for hydromotor up to 255cc/rev
- THE Solution. New range of interchangeable Transmissions for Hydrostatic & Electric applications
- THE Solution. Proprietary synchronized and Powershift architecture
| Operative Weight (Ton) | Front axle | Rear axle | Hydrostatic Transmissions | ECU |
|---|---|---|---|---|
| From 1 to 4 | 48.08M 48.12M 48.16M | 48.08M 48.12M 48.16M | TB135C TB172C TB172HVT TB172/2C Stop&Go | |
| From 4 to 9,5 | 48.18M 28.20 28.25 28.32 | 48.18M 28.20 28.25 28.32 | TB172C TB172HVT TB172/2C Stop&Go TB172/2C Shift on Fly THE260/2 Synchro | Yes Yes |
| From 9,5 to 13 | 28.43M 48.50M 48.57M | 28.43M 48.50M 48.57M | TB172/2C Stop&Go TB172/2C Shift on Fly THE260/2 Synchro THE260/2 PS | Yes Yes Yes |
Compact Wheel Loader
Axles
Key Features and Benefits
- The 46-Series Axles generation provides increased efficiency
- E-Axles range with input flanged e-Motor suitable for mini and compact wheel loaders
- P3 and P4 solutions for HEV and BEV
Transmissions
Key Features and Benefits
- Single speed and dual speed eGearboxes specifically designed for electric vehicles
- THE Solution. New range of interchangeable Transmissions for Hydrostatic & Electric applications
- THE Solution. Proprietary synchronized and Powershift architecture
- eMotors range suitable for low and high voltage
Axles
Key Features and Benefits
- The 46-Series Axles generation provides increased efficiency
- E-Axles range with input flanged e-Motor suitable for mini and compact wheel loaders
- P3 and P4 solutions for HEV and BEV
Transmissions
Key Features and Benefits
- Single speed and dual speed eGearboxes specifically designed for electric vehicles
- THE Solution. New range of interchangeable Transmissions for Hydrostatic & Electric applications
- THE Solution. Proprietary synchronized and Powershift architecture
- eMotors range suitable for low and high voltage
| Operative Weight (Ton) | Front axle | Rear axle | eGearbox | eMotor | ECU |
|---|---|---|---|---|---|
| From 1 to 4 | 48.08M 48.12M 48.16M | 48.08M 48.12M 48.16M | TB172C TB220 | 200 Series 200 Series | Yes Yes |
| From 4 to 9,5 | 48.18M 28.20 28.25 28.32 | 48.18M 28.20 28.25 28.32 | TB172C TB200 THE260/2 Synchro | 200 Series 200 Series 200 Series | Yes Yes Yes |
| From 9,5 to 13 | 28.43M 48.50M 48.57M | 28.43M 48.50M 48.57M | THE260/2 Synchro THE260/2 PS | 270 Series 270 Series | Yes Yes |
Blackhoe Loader
Axles
Key Features and Benefits
- The most complete range in the market, suitable for the compact up to the heavy and premium architectures
- Each axle model is available with several reduction ratios, multiple widths, and
various vehicle mounting interfaces. - High load capacity and robust gear design ensure extended durability
Transmissions
Key Features and Benefits
- Power Shuttle, SPS, and 4 or 6-speed Powershift
- Central and side drive configurations
- Full electronic or electro-hydraulic control
- Smooth, precise, and reliable response even under severe working conditions granted
Axles
Key Features and Benefits
- The most complete range in the market, suitable for the compact up to the heavy and premium architectures
- Each axle model is available with several reduction ratios, multiple widths, and
various vehicle mounting interfaces. - High load capacity and robust gear design ensure extended durability
Transmissions
Key Features and Benefits
- Power Shuttle, SPS, and 4 or 6-speed Powershift
- Central and side drive configurations
- Full electronic or electro-hydraulic control
- Smooth, precise, and reliable response even under severe working conditions granted
| Engine Power (Kw) | Front axle | Rear axle | Torque Converter Transmissions | ECU |
|---|---|---|---|---|
From 50 to 82 | 26.00 26.16 26.17 | 28.32M 28.40 | TCB80 2WD TCB80 | |
From 70 to 82 | 26.17 26.22 26.22M | 28.43M 28.44 | TCB80 TCB80 SPS | Yes |
| From 75 to 90 | 26.24M | 28.50 | TCB90 PS | Yes |
Blackhoe Loader
Axles
Key Features and Benefits
- The most complete range in the market, suitable for all machine size
- All steering axles enable a tight steering radius, while ensuring precise handling, high maneuverability, and minimum tyre wear.
Transmissions
Key Features and Benefits
- Power Shuttle, SPS, and 4 or 6-speed Powershift
- Central and side drive configurations
- Full electronic or electro-hydraulic control
- Smooth, precise, and reliable response even under severe working conditions granted
Axles
Key Features and Benefits
- The most complete range in the market, suitable for all machine size
- All steering axles enable a tight steering radius, while ensuring precise handling, high maneuverability, and minimum tyre wear.
Transmissions
Key Features and Benefits
- Power Shuttle, SPS, and 4 or 6-speed Powershift
- Central and side drive configurations
- Full electronic or electro-hydraulic control
- Smooth, precise, and reliable response even under severe working conditions granted
| Engine Power (Kw) | Front axle | Rear axle | Torque Converter Transmissions | ECU |
|---|---|---|---|---|
From 70 to 82 | 26.28M 26.32M 26.38M | 26.32M 26.38M | TCB80 TCB80 SPS | Yes |
| From 75 to 90 | 26.43M 26.48M | 26.43M 26.48M | TCB90 PS | Yes |
Blackhoe Loader
Axles
Key Features and Benefits
- The most complete range in the market, suitable for all machine size
- All steering axles enable a tight steering radius, while ensuring precise handling, high maneuverability, and minimum tyre wear.
- P3 solutions for HEV and BEV vehicles
Transmissions
Key Features and Benefits
- THE Solution. New range of interchangeable dual speed Transmissions for Hydrostatic & Electric applications
- THE Solution. Proprietary synchronized and Powershift architecture
- eMotors range suitable for low and high voltage
Axles
Key Features and Benefits
- The most complete range in the market, suitable for all machine size
- All steering axles enable a tight steering radius, while ensuring precise handling, high maneuverability, and minimum tyre wear.
- P3 solutions for HEV and BEV vehicles
Transmissions
Key Features and Benefits
- THE Solution. New range of interchangeable dual speed Transmissions for Hydrostatic & Electric applications
- THE Solution. Proprietary synchronized and Powershift architecture
- eMotors range suitable for low and high voltage
| Engine Power (Kw) | Front axle | Rear axle | eGearbox | eMotor | ECU |
|---|---|---|---|---|---|
| From 50 to 82 | 26.00 26.16 26.17 | 28.32M 28.40 | TB220 THE260/2 Synchro THE260/2 PS | 270 Series 270 Series 270 Series | Yes Yes Yes |
From 70 to 82 | 26.17 26.22 26.22M | 28.43M 28.44 | TB220 THE260/2 Synchro THE260/2 PS | 270 Series 270 Series 270 Series | Yes Yes Yes |
| From 75 to 90 | 26.24M | 28.50 | THE260/2 Synchro THE260/2 PS | 270 Series 270 Series | Yes Yes |
Wheeled Excavator
Axles
Key Features and Benefits
- Full range of modular front and rear steering axles for 4WS version
- Rear rigid axles for 2WS version
- The 46-Series Axles generation provides increased efficiency for the compact range
- Wheel-end wet brakes for standard range
Transmissions
Key Features and Benefits
- Complete range from compact dropbox to fully electronically controlled solutions
- Suitable for hydromotor up to 255cc/rev
- THE Solution. New range of interchangeable Transmissions for Hydrostatic & Electric standard range
Axles
Key Features and Benefits
- Full range of modular front and rear steering axles for 4WS version
- Rear rigid axles for 2WS version
- The 46-Series Axles generation provides increased efficiency for the compact range
- Wheel-end wet brakes for standard range
Transmissions
Key Features and Benefits
- Complete range from compact dropbox to fully electronically controlled solutions
- Suitable for hydromotor up to 255cc/rev
- THE Solution. New range of interchangeable Transmissions for Hydrostatic & Electric standard range
| Operative Weight (Ton) | Front axle | Rear axle Steering / Rigid | Hydrostatic Transmissions | ECU |
|---|---|---|---|---|
| From 5 to 7 | 26.09M 26.16M | 26.09M / 28.09M 26.16M / 28.16M | TB135C TB172C TB172/2C Stop&Go | |
| From 7 to 13 | 26.25M 26.27M | 26.25M / 28.25M 26.27M | TB172C TB172HVT TB172/2C Stop&Go TB172/2C Shift on Fly THE260/2 Synchro | Yes Yes |
| From 15 to 23 | 26.38E | 26.38E / 28.38E | TB172/2C Stop&Go THE260/2 PS | Yes |
Wheeled Excavator
Axles
Key Features and Benefits
- Full range of modular front and rear steering axles for 4WS version
- Rear rigid axles for 2WS version
- The 46-Series Axles generation provide increased efficiency for the compact range
- Wheel-end wet brakes for standard range
Transmissions
Key Features and Benefits
- Complete range from compact dropbox to fully electronically controlled solutions
- THE Solution. New range of interchangeable Transmissions for Hydrostatic & Electric standard range
- eMotors range suitable for low and high voltage
Axles
Key Features and Benefits
- Full range of modular front and rear steering axles for 4WS version
- Rear rigid axles for 2WS version
- The 46-Series Axles generation provide increased efficiency for the compact range
- Wheel-end wet brakes for standard range
Transmissions
Key Features and Benefits
- Complete range from compact dropbox to fully electronically controlled solutions
- THE Solution. New range of interchangeable Transmissions for Hydrostatic & Electric standard range
- eMotors range suitable for low and high voltage
| Operative Weight (Ton) | Front axle | Rear axle Steering / Rigid | eGearbox | eMotor | ECU |
|---|---|---|---|---|---|
| From 5 to 7 | 26.09M 26.16M | 26.09M / 28.09M 26.16M / 28.16M | TB172C TB220 | 200 Series 200 Series | |
| From 7 to 13 | 26.25M 26.27M | 26.25M / 28.25M 26.27M | TB220 THE260/2 Synchro | 200 Series 270 Series | Yes Yes |
| From 15 to 23 | 26.38E | 26.38E / 28.38E | THE260/2 PS | 270 Series | Yes |
Aerial Working Platform
Axles
Key Features and Benefits
- Full range of modular front and rear steering axles for 4WS version
- Rear rigid axles for 2WS version
- Heavy duty axles for solid tires
- Covering all sizes of telescopic, articulating boom, and scissors lifts.
Transmissions
Key Features and Benefits
- Range of single speed compact dropbox available
- Several reduction ratios available
- Remote mounting or input axle mounting
- Vertical or horizontal orientation
Axles
Key Features and Benefits
- Full range of modular front and rear steering axles for 4WS version
- Rear rigid axles for 2WS version
- Heavy duty axles for solid tires
- Covering all sizes of telescopic, articulating boom, and scissors lifts.
Transmissions
Key Features and Benefits
- Range of single speed compact dropbox available
- Several reduction ratios available
- Remote mounting or input axle mounting
- Vertical or horizontal orientation
| Operative Weight (Ton) | Front axle | Rear axle Steering / Rigid | Hydrostatic Transmissions | ECU |
|---|---|---|---|---|
| Up to 8 | 26.09M 26.16M | 26.09M / 28.09M 26.16M / 28.16M | TB135C | |
| From 8 to 12 | 26.20M 26.22M | 26.20M / 28.20M 26.22M / 28.22M | TB172C | |
| From 12 to 19 | 26.27M 26.28M | 26.27M / 28.27M 26.28M | TB172C | |
| From 19 to 24 | 26.32M 26.43M | 26.32M 26.43M | TB172C |
Aerial Working Platform
Axles
Key Features and Benefits
- Full range of modular front and rear steering axles for 4WS version
- Rear rigid axles for 2WS version
- Heavy duty axles for solid tires
- Covering all sizes of telescopic, articulating boom, and scissors lifts.
Transmissions
Key Features and Benefits
- Single speed eGearboxes specifically designed for electric vehicles, for standard and high input speed
- Several reduction ratios available
- Remote mounting or input axle mounting
- eMotors range suitable for low and high voltage
Axles
Key Features and Benefits
- Full range of modular front and rear steering axles for 4WS version
- Rear rigid axles for 2WS version
- Heavy duty axles for solid tires
- Covering all sizes of telescopic, articulating boom, and scissors lifts.
Transmissions
Key Features and Benefits
- Single speed eGearboxes specifically designed for electric vehicles, for standard and high input speed
- Several reduction ratios available
- Remote mounting or input axle mounting
- eMotors range suitable for low and high voltage
| Operative Weight (Ton) | Front axle | Rear axle Steering / Rigid | eGearbpx | eMotor | ECU |
|---|---|---|---|---|---|
| Up to 8 | 26.09M 26.16M | 26.09M / 28.09M 26.16M / 28.16M | TB135C TB220 | 200 Series 200 Series | Yes Yes |
| From 9 to 12 | 26.20M 26.22M | 26.20M / 28.20M 26.22M / 28.22M | TB172C TB220 | 200 Series 270 Series | Yes Yes |
| From 12 to 19 | 26.27M 26.28M | 26.27M / 28.27M 26.28M | TB172C TB220 | 270 Series 270 Series | Yes Yes |
| From 19 to 24 | 26.32M 26.43M | 26.32M 26.43M | TB172C TB220 | 270 Series | Yes |
Soil Compactor
Axles
Key Features and Benefits
- Complete range of rear-drive axles
- Modular structure integrating specific features for this application
- Direct mounting for the hydrostatic motor
- High reduction ratio, obtained through either a hypoid gear set or an input dropbox
Axles
Key Features and Benefits
- Complete range of rear-drive axles
- Modular structure integrating specific features for this application
- Direct mounting for the hydrostatic motor
- High reduction ratio, obtained through either a hypoid gear set or an input dropbox
| Operative Weight (Ton) | Rear axle |
|---|---|
| From 5 to 9 | 28.16M |
| From 8 to 11 | 28.25M |
| From 11 to 17 | 28.32M 28.43M |
| From 17 to 23 | 28.60M |
Download the whole CE catalogue
For further information about our products, please contact drivelines@carraro.com
CE Brochure 2022
23 October 2022, 7.33 MB, pdf
Download
We've been working closely for many years with the world's main producers in the earth-moving and construction machinery sector. We develop gears and transmission systems for backhoe loaders, general loaders, telehandlers, wheeled excavators and compactors.
Each system involves a combination of axles and a hydrostatic or hydrokinetic transmission with torque converter, with semi-automatic or fully automatic operation via the electronic control unit that manages the entire system. Every system component or module is designed to guarantee first-class vehicle efficiency and productivity.
Thanks to our Maniago plant, SIAP Spa, we have the most advanced skills and technologies for processing different types of steel cut gears for applications operating on construction sites. In particular: cylindrical gears with helical and straight-tooth teeth, ring gears for planetary drives, spiral bevel gears for differential gear units, pinions for planetary drives.
eCarraro
The future is electric and hybrid
Gears
Precision is crucial for every movement. For over 30 years we've been a leading partner in the production of gears for agricultural machines, construction vehicles, goods handling vehicles and cars. We make mechanical components for wind power, industrial and railway applications as well.
Transmission systems
We design and develop transmission systems for agricultural machines and construction equipment, combining mechanics, hydraulics and electronics to guarantee optimum vehicle efficiency.
