Material handling

Transmission systems for a safe and efficient use.

We design and produce transmission/engine systems for the material handling industry, for use on counterbalanced trucks, airport vehicles, pallet trucks and 3- or 4-wheel electric trucks. Our systems combine mechanics, hydraulics, electronics and electric drive for a safe and efficient performance.

The range for the goods handling industry also includes bevel gears, ground gears and complete units designed for electric trucks.

Gears

Cut steel gears

Cylindrical gears with helical toothing and straight teeth for goods handling.

Production processes
Min. diam.
Max. diam.
Min. mod.
Max. mod.
Gear cutting
20 mm1000 mm1,5 mm28 mm
Shaving
35 mm400 mm1,5 mm28 mm
Teeth grinding
35 mm900 mm1,5 mm16 mm
Press hardening
150 mm500 mm----

Epicyclic ring gears

Ring gears for planetary drives, for material handling

Broached
Production processes
Min. diam
Max. diam.
Face width
Max. mod.
Broaching
20 mm350 mm15-150 mm5 mm
Carburisation
--500 mm----
Nitriding
--700 mm----
Slotted
Production processes
Min. diam
Max. diam.
Face width
Max. mod.
Slotting
20 mm700 mm220 mm12 mm
Carburisation
--500 mm----
Nitriding
--700 mm----
Press hardening
--400 mm----

Bevel gears

Spiral bevel gears, for differential gear units.

Production processes
Min. diam
Max. diam.
Face width
Max. mod.
Gear cutting (Gleason)
50 mm450 mm1,5 mm12 mm
Gear cutting (Oerlikon)
20 mm425 mm1,5 mm12 mm
Teeth grinding (Gleason)
50 mm400 mm1,5 mm11 mm
Lapping
--600 mm----
Press hardening
--500 mm----

Axles and transmission systems

Electric trucks (class 1)

A range of 4-wheel forklifts, ground support equipment and airport vehicles for load handling.

Electric trucks (class 4-5)

A range of transmission systems for counterbalanced and internal combustion forklifts, for goods handling.

Single-reduction axles

Single-reduction axles for electric trucks and ground support equipment.

Special axles

Special axles for electric trucks and ground support equipment for airports.
